MasterLam reel to sheet laminator

Technical Specifications

Expert Single-facer

Technical specifications

Sheet feeder

Details

• Automatic vacuum assisted feeding section to transfer sheets into the laminating unit.
• Complete system, including a vacuum pomp.
• Automatic lifting for the pre-printed sheet stack.
• Stack loading direct on the sheet feeder table.
• Maximum stack height 1600 mm (63").

Pre printed sheet transport system

Details

• Possibility to correct the position of the stack in respect to the centreline moving it side-ways.
• Shingling conveyor system to transport sheets to the leading edge, to be positioned before meeting the single face web.
• Vacuum belt for perfect transportation of the printed sheets.
• Including hold down and transport mechanism for synchronization.
• Servo-drive system with computer controls.
• High speed missing sheet detector.

Knife and glue unit

Details

• Rail mounted for easy inspection, cleaning and maintenance.
• Powered roll back with audio signal.
• Positive pneumatic locking of section.
• High precision unit with three chrome plated rolls.
• Computer controlled motorized lifting of glue pressure roll.
• Micrometric gap adjustment with verniers for precise control and minimal glue application.
• Electronic glue level control with two easily disconnected glue feeders.
• Complete with special de- signed pump. Glue pipes to be connected to the manufacturer's glue tank. Water connection for easy cleaning of the glue unit. (semi-automatic)
• Electronic controlled calliper setting with correction feature and memory.
• Separate idling drive automatically activated during machine stoppages.
• Lower Roll automatically retract from glue applicator roll when the machine stops and positions itself to the memorized gap when starting again.
•Two rotary cylinders for the knives, controlled by a servo-motor, ready to work at 10.000 sh/h, 150 m/min (490 ft/min), with perfect accuracy.
• Great stainless steel pan with 2 positions: one for normal work and one for semi-automatic cleaning.
• Plexiglas guards.

Registration and laminating section

Details

• Floor mounted section.
• Computer controlled pneumatic system for the positioning of both lea- ding edges of the printed sheets.
• Special light introduction wheel system, with computer-controlled servo-drive, to regulate speed of acceleration and deceleration, joining the leading edge of printed sheet and the leading edge of the single-faced web at line speed.
• More or less overlapping as chosen in the job program and adaptable at any time even when running machine. Wheel lifting activated by pneumatic actuators.
• A gauging roll ensures proper adhesion and maintains registration between the pre printed sheet and the recently formed single face sheet. It will lift automatically in case of a missed sheet to avoid glue to be deposited on it.
• Short bonding belt at machine speed establishing a correct contact between both sheets before entering in the final compression section.

Compression belt sheet to sheet and drying belt

Details

• The laminated sheets are pressed individually between two belts, granting an uniform bond. Thereafter they enter the belt press.
• The drying belt consists of an upper and lower conveyor belt, which cover the entire working width. The shingling distance is variable. The upper belt can be adjusted for different format.

Automatic non-stop stacker with inverter

Details

• To collect a pre-selected number of laminated sheets and stack them automatically, whether alternatively inverted or not, into a straight finished stack.
• This group is completely independent of the main machine.

The machine executes the following working sequence:

1. Collection of sheets coming from the drying conveyor, which is practically not inclined, and placing them in a handful.
2. When the package has reached 20-30 sheets (adjustable), this handful is transported towards the turnover section horizontally.
3. In the turnover section, it is turned and dropped into the stacking unit.
4. Finally, the handful is introduced into the final stack.
5. The stacker is equipped with a non-stop device.
6. Once the pallet of the stack has been completed, it will automatically leave on rollers to the client's conveyor.

Single facer unit with cassettes

Details

• Single-face unit with cassettes for various fluting.
• Vertical roll stack configuration.
• Vacuum-assisted fingerless process.
• Corrugating roll made of high-quality alloyed steel, machined in standard or special profiles, induction-hardened, and precision-ground.
• Roll diameter of 240 mm (9.44").
• Positive traction of the lower corrugating roll by means of a reinforced cardan shaft directly from the main gearbox.
• Loading of the rolls by means of pneumatic cylinders.
• Complete with DC main drive and electronic drive.
• High-precision glue unit and automatic fine adjustment for glue application.
• Chrome-plated glue rolls with a screened applicator roll.
• Directly driven separately by a cardan shaft.
• Independent idling drive during machine stoppages.
• Pneumatically positioned glue unit at three different points.
• Pre-heater for liner paper of 320 mm (12.59") diameter directly attached to the machine.
• Solid metallic structure with take-up unit and transport belts.
• Incline conveyor and horizontal conveyor, with a motor and electrical controls, with a synchronization system.
• Edge trimming device with the possibility of making a central slit.
• Including hold-down and transport mechanism for synchronization.
• Adjustable trim collectors to be connected to a shredder or fan.
• Side guides, controlled from below.
• One rotating preheating cylinder with wrap arm adjustment, for liner and medium paper of 600 mm (23.62"), motorized adjusting angle between 60 and 300 degrees.
• Two shaftless hydraulic duplex reel-stands.
• Reel-stands to ease the work of the operators.
• All movements are controlled hydraulically and electrically by motors.
• Double arm for loading two reels at a time.
• Cones suitable for 75-100 mm (2.95"-3.93") cores.
• Disk braking system pneumatically adjustable.
• Possibility to work off the center line.
• Maximum reel diameter of 1500 mm (59").
